Aluminum FIFO Monorail Terminal 40 mm
The MONO-EK-HD-40 end piece is the heavy-duty version for the busiest FIFO Monorail 40 mm lanes and high loads: its V shape lets trolleys in and out easily. It locks into the rail slots with integrated plates and grub screws; 4 holes to screw it to the floor.
Black powder-coated aluminium, 192.86 × 120.85 × 22.94 mm, 260 g. Takes connecting plates for multi-lane stations. Pack of 1.
Lean Logistic · FIFO Monorail accessories
FIFO Monorail 40 mm HD aluminium end piece
The extra-robust end piece for the busiest Monorail 40 mm lanes: in black-painted aluminium, with a V shape for loading and unloading trolleys effortlessly. It slots into the rail slots with the integrated plates and is also screwed to the floor.
Designing a FIFO station? Configure it starting from your cart →
Why choose it
For high loads
The robust material makes it suitable for high-traffic areas and high loads.
V-shaped entry
Trolleys in and out of the lane with ease.
Connecting plates
It takes the FIFO Monorail joining plates for multi-lane stations.
Data and compatibility
| Specification | Value |
|---|---|
| Code | MONO-EK-HD-40 |
| Compatible with | FIFO Monorail 40 mm rail (MONO-BP-1200/1800/2400) |
| Pack | 1 piece |
| Material | Powder-coated aluminium, black |
| Dimensions | 192.86 × 120.85 × 22.94 mm |
| Weight | 260 g |
| Temperature | from -80 to +150 °C (short term) |
| Mounting | Guides in the slots, locked with grub screws (3 mm Allen key); 4 holes for floor screws |
With particularly high loads also screw it to the floor, with button-head or cheese-head screws.
FIFO Monorail 40 mmCompatible rail
FIFO Monorail 40 mm - Connection platesConnecting plates
Plastic Monorail Terminal 40-mmStandard plastic end pieceDo you need a component for your FIFO lane?
Tell us which rail you use and what the station looks like: we will confirm the right codes and quantities.
