Terminal for FIFO rails
The FIFO-EK-2L left and FIFO-EK-2R right end pieces close the entry of the FIFO Station floor rail with a wedge: the trolley rolls in without knocks and the rail stays in place. Compatible with FIFO-BP rails from 1200 to 3000 mm.
Polyamide 6 with 50% glass fibre, signal black RAL 9004. Acrylic adhesive over the full surface and 3 holes for screws and anchors (FIFO-SCHR-K set). Pack of 1.
Documents
Lean Logistic · FIFO lane accessories
Left and right end pieces for FIFO Station rails
The wedge end pieces that close the entry of the FIFO lane: the trolley enters without impacts and the rail stays put. They are made of glass-filled polyamide, with adhesive over the whole surface and 3 holes for fixing to the floor with screws and wall plugs.
Designing a FIFO station? Configure it starting from your cart →
Why choose it
Easy entry
The wedge shape leads the trolley castors into the lane, without knocks.
Double hold
Acrylic adhesive over the whole surface and 3 holes for screw fixing: the lane does not move.
Robust
Polyamide 6 with 50% glass fibre, signal black, resistant to plasticisers.
Data and compatibility
| Specification | Value |
|---|---|
| Codes | FIFO-EK-2L left end piece; FIFO-EK-2R right end piece |
| Compatible with | FIFO Station rail FIFO-BP-1200/1800/2400/3000 |
| Pack | 1 piece |
| Material | PA6 with 50% glass fibre (GF50), signal black RAL 9004, silicone-free |
| Fixing | Acrylic adhesive over the whole surface + 3 screw holes |
| Average adhesive strength | 10.8 N/cm |
| Temperature | 70 °C for short periods, 60 °C continuous; ideal installation 18–25 °C |
| Screws and wall plugs | FIFO-SCHR-K set |
With side-by-side rails use the FIFO-EK-1 double end piece; on the picking side you can use the FIFO-PAK-L/R short end pieces.
Modular rail FIFO StationCompatible rail
Fixing Screw 6x40 mmScrews and anchors for fixing
Dual Terminal for FIFO railsDouble end pieceDo you need a component for your FIFO lane?
Tell us which rail you use and what the station looks like: we will confirm the right codes and quantities.
