Frame series 100
https://leanproducts.eu/shop/frame-series-100-96 https://leanproducts.eu/web/image/product.template/96/image_1920?unique=d3bbd8eThe series 100 frame is a double-sided anti-glare PVC hanging information frame designed for identifying racks, storage areas and parking areas. Available in DIN A3, A4 and A5 formats, it suits many configurations thanks to its compatibility with a wide range of mounting accessories. It is supplied in packs of 5 pieces and in eight colour options (Red, White, Blue, Yellow, Green, Black, Orange, Light grey) to support visual colour-coding systems.
September 2026 update — part numbers
The part numbers of this range have changed. The products themselves are unchanged.
ORGATEX · Information frames for warehouse and production
Frame series 100: double-sided A5–A3 information frames for warehouses
Sturdy plastic frames for warehouse signs, instructions, location codes and KPIs, displayed where they are needed: on racks, storage areas, parking spaces, boxes and machines. The printout on standard DIN paper goes into the anti-glare PVC sleeve, readable by scanners, and is quickly changed. They read from both sides and work in portrait or landscape.
Why choose it
Built for industry
Sturdy plastic frame (ABS), lighter than conventional frames: it stands up to use even in demanding industrial areas.
Scanner-readable
The anti-glare PVC protective sleeve shields the sheet and lets all standard scanners read the barcodes.
Quick sheet change
Print on standard DIN paper, slide the sleeve in from the short side and the patented closure clip keeps it in place.
5S colour code
8 colours to tell departments, flows or statuses apart; the same frame works in portrait or landscape.
Choose it if…
- you need to identify racks, storage areas or parking spaces with A5 to A3 signs
- the sign hangs and must be read from both sides
- you want to change the sheet often, printed on standard paper
- you need a colour code for departments, flows or statuses
Choose another solution if…
- if you need large A2 or A1 formats, readable from afar Frame series 200 →
- if you want a complete 5S set with tube and 6 frames 5S Suspension Set →
- if the sign goes on the wall and you want to open the frame from the front Aluminium information board →
- if the document goes on a magnetic board Magnetic Windows - Magnetic Document Window →
Not sure which one to choose? Use the Visual Management guide →
How to mount it: an accessory for every place
From the ceiling
Magnet with hook for metal ceilings, clips for suspended ceilings, metal chain and S-hooks.
View product →On tubes
Clip holders for Ø 28–30 mm and Ø 35–38 mm tubes, or the Ø 28 tube clip with an adjustable universal frame clip.
View product →On the wall
Self-adhesive holder with screw hole, 360° rotating screw-on holder or the wall kit to flip through 5 frames.
View product →On boxes and baskets
Clamp holder for box walls up to 20 mm and hooks for wire baskets with wire up to 10 mm.
View product →Free-standing
Floor stand for A4 frames with metal base and chrome tube adjustable from 320 to 620 mm.
View product →The rotating connector links several frames in a row; the cube hinges join four frames into a display readable from four sides.
Technical data
| Colour | Red, white, blue, yellow, green, black, orange, light grey |
| DIN formats | A3, A4, A5 |
| Pack | 5 pcs |
Inner/outer size (W × H): A5 148 × 210 / 153 × 218 mm, A4 210 × 297 / 217 × 305 mm, A3 297 × 420 / 305 × 427 mm. Plastic frame with anti-glare PVC protective sleeve, for portrait or landscape use.
Images and applications


Accessories and related products
Need help choosing?
We recommend the right format, fixing and accessories for your department, warehouse or office. For large quantities or recurring supplies we'll prepare a tailored quote.
Specifications
| Colour | Red or White or Blue or Yellow or Green or Black or Orange or Light grey |
| DIN formats | A3 or A4 or A5 |
| Pack | 5 pcs |
| Tags | |
|---|---|
| Tags |
Orgatex
|
Print the document on DIN paper, put it in the PVC protective sleeve and slide it into the frame from the short side. The closure clip stops the sleeve from slipping out; the clip is also available as a spare part.
Yes: the PVC protective sleeve is anti-glare and can be read by all standard scanners without removing the sheet.
On metal ceilings with the magnet with hook, on suspended ceilings with the ceiling clip; from there run the metal chain and S-hooks down to the rotating hanging eyelet on the frame.
Yes: the rotating connector links several 100 series frames in a row, and the cube hinge joins four at 90° for a display readable from four sides. With the wall kit for 5 frames you flip through them like the pages of a book.
Standard pockets, label holders and magnetic labels are designed for indoor use, and information frames are suitable for indoor use only. Outdoors, in wet areas and where there are water splashes, use the Outdoor document holder: the zip on the bottom edge protects the document from wet, dirt and mechanical stress. It comes in A5 and A4 landscape, blue or yellow, self-adhesive, magnetic or hanging; it withstands -20 to +80 °C for short periods. For pallets there is the pallet clip, suitable for indoor and outdoor use.
On a metal board or wall, Magnetic Windows® hold documents without sleeves and are written on with non-permanent markers; magnetic headers name the sections and magnetic clipboards hold the forms to fill in. To hang the rules above the workstation there is the 5S suspension set: a 2420 mm steel tube, three white A3 frames and three A4 frames in yellow, green and red, with clamps and hooks. For cleaning tools there is the 5S cleaning station. Use colours consistently for departments, statuses or responsibilities.
